This book is concerned with circuit simulation using National Instruments Multisim. It focuses on the use and comprehension of the working techniques for electrical and electronic circuit simulation. The first chapters are devoted to basic circuit analysis. It starts by describing in detail how to perform a DC analysis using only resistors and independent and controlled sources. Then, it introduces capacitors and inductors to make a transient analysis. In the case of transient analysis, it is possible to have an initial ...
Read More
This book is concerned with circuit simulation using National Instruments Multisim. It focuses on the use and comprehension of the working techniques for electrical and electronic circuit simulation. The first chapters are devoted to basic circuit analysis. It starts by describing in detail how to perform a DC analysis using only resistors and independent and controlled sources. Then, it introduces capacitors and inductors to make a transient analysis. In the case of transient analysis, it is possible to have an initial condition either in the capacitor voltage or in the inductor current, or both. Fourier analysis is discussed in the context of transient analysis. Next, we make a treatment of AC analysis to simulate the frequency response of a circuit. Then, we introduce diodes, transistors, and circuits composed by them and perform DC, transient, and AC analyses. The book ends with simulation of digital circuits. A practical approach is followed through the chapters, using step-by-step examples to introduce new Multisim circuit elements, tools, analyses, and virtual instruments for measurement. The examples are clearly commented and illustrated. The different tools available on Multisim are used when appropriate so readers learn which analyses are available to them. This is part of the learning outcomes that should result after each set of end-of-chapter exercises is worked out. Table of Contents: Introduction to Circuit Simulation / Resistive Circuits / Time Domain Analysis -- Transient Analysis / Frequency Domain Analysis -- AC Analysis / Semiconductor Devices / Digital Circuits
Read Less
Add this copy of Circuit Analysis with Multisim to cart. $88.06, new condition, Sold by Just one more Chapter rated 3.0 out of 5 stars, ships from Miramar, FL, UNITED STATES, published 2011 by Morgan & Claypool.
Add this copy of Circuit Analysis With Multisim (Synthesis Lectures on to cart. $507.00, good condition, Sold by tLighthouseBooks rated 2.0 out of 5 stars, ships from Onekama, MI, UNITED STATES, published 2011 by Morgan & Claypool Publishers.
